ArtiDiag500 - Android based OBD II Diagnostic Scan Tool

The ArtiDiag500 scanner provides OE level compatible use for Domestic, Asian and European vehicles 1996 and newer. AutoVIN feature for faster vehicle identification and easy vehicle battery voltage display. Designed to diagnose PCM, Automatic Transmission, ABS and SRS System with our entry level Android based scan tool. Quickly and effectively access all modes of OBDII. Featuring a 5” Touch screen and easy 1-touch update the ArtiDiag500 is a convenient and handy tool that makes collecting and reading diagnostic information fast and easy. Comes with free software updates and 1 year hardware warranty. Multi-Lingual support.


Features

  • Four System Diagnostics - Engine, Transmission, ABS, and SRS Systems
  • Diagnostics for 42 Vehicle Makes
  • Access to ECU Information
  • Read DTCs
  • Clear DTCs
  • Display Live Data Stream
  • One-touch AutoVIN Technology: automatically identify the vehicle, and match the proper diagnostic software.
  • Vehicle History function: offer direct access to the previous diagnostic procedure
  • Automatically Generated Diagnostic Report can be shared via email
  • Battery Voltage Monitor: Displays vehicle battery voltage in real time
  • One-click wireless update via Wi-Fi
  • DTC Look-up Library for detailed DTC explanation
  • Feedback function for online technical assistance
  • Graph and Merge Live Data Stream for easy analysis

OBDII Functions

  • Read DTCs
  • Clear DTCs
  • Live Data
  • I/M Readiness Monitor Status
  • View Freeze Frame Data
  • O2 Sensor Test
  • On-board Monitor Test
  • EVAP Test (Mode$8)
  • Read Vehicle Information

Specifications

  • Display: LCD 5-Inch, 1280*720 dpi
  • Operating system: Android 7.1
  • Operating voltage: 9~18V
  • Storage Temperature : -20℃~70℃ (-4℉~158℉)
  • Working Temperature : -10℃~50℃ (14℉~122℉)
  • Dimension: 232*126*34 mm (9.1*5.0*1.3 inch)
  • Package size: 272*218*80 mm (10.70*8.58*3.15 inch)
  • Length: 185 mm(7.28 inch)
  • Net Weight: 565g ( 19.92oz)
  • Multilingual Support: English, French, German, Spanish, Portuguese, Russian, Japanese, Italian

Package List

  • ArtiDiag500
  • Diagnostic Cable
  • Charging Cable
  • Quick start Guide
  • User's Manual
  • Carrying Bag
